MG A3

Product Introduction:

The MGA3 type medical gas pressure alarm is specifically designed for hospital gas systems. It is used to monitor the pressure status of medical gases such as oxygen, nitrous oxide, and compressed air in real time, ensuring the stable operation of life support systems, operating room gas supply, and ward gas delivery. It supports upper/lower pressure alarms and can flexibly adapt to multiple scenarios such as gas manifold, central gas supply pipelines, and terminal equipment pressure standards (such as an oxygen pressure threshold of 0.4MPa to 0.6MPa).

Share To:

INQUIER NOW

Add To Cart

PRODUCT DESCRIPTION
TECHNICAL SPECIFICATIONS
INQUIRE IMMEDIATELY
RELATED PRODUCTS

PRODUCT DESCRIPTION

Features:

1. The sensor is made of H58-3 brass material and is compatible with medical gases such as oxygen, nitrous oxide, and carbon dioxide.

2. The communication range of the sensor can be extended up to 100 meters, meeting the requirements of multi-area monitoring.

3. The measurement range is positive pressure 0-1000 MPa,negative pressure -100 to 0 MPa. The positive and negative pressure sensors are interchangeable.

4. Alarm response time ≤ 1 second.

5. Provide passive switch quantities, high and low pressure alarm signal outputs, and can be connected to the operating room information panel.

6. Pressure unit (MPa, psi, bar, mmHg) etc. can be modified on-site.

TECHNICAL SPECIFICATIONS

Model	Power consumption	Sensor connector size	L(mm)	W(mm)	H(mm)
1 Air	2W	6YC	200	180	45
2 Air	3W	6YC	240	180	45
3 Air	4W	6YC	340	180	45
4 Air	5W	6YC	440	180	45
5 Air	6W	6YC	540	180	45
6 Air	7W	6YC	640	180	45
7 Air	8W	6YC	740	180	45
